Eaton M-Max series Quick Start Guide

M-Max Series adjustable frequency drive
36 For more information visit: www.eaton.com
MN04020002E
February 2010
Table 11: All Parameters (continued)
PNU ID
Access
Right
RUN Designation Value Range
Factory
Setting
User
Setting
Digital Output (continued)
P5.1
(con’t.)
313 ✓ RO1 signal 16 = Flow control active
17 = Flow control, single step
18 = Flow control, program cycle
completed
19 = Flow control, pause
20 = Counter reference value 1 active
21 = Counter reference value 2 active
22 = RUN signal active
23 = 4 mA warning
24 = Result of logic function
25 = PID controller, process value
monitoring
26 = External brake actuated
27 = Current monitoring
28 = Field bus signal switched through
2
P5.2 314 ✓ RO2 signal Like P5.1 3
P5.3 312 ✓ DO1 signal Like P5.1 1
P5.4 315 ✓ Frequency
monitor
0 = Deactivated
1 = Minimum
2 = Maximum
0
P5.5 316 ✓ Frequency
monitor,
reference value
0.00 – 320.00 Hz 0.00
P5.6 346 ✓ Frequency
monitor [2]
0 = Deactivated
1 = Minimum value
2 = Maximum value
0
P5.7 347 ✓ Frequency
monitor [2],
reference value
0.00 – 320.00 Hz 0.00
P5.8 1457 ✓ Current monitor,
reference value
0.00 – I
e
A 0.00
P5.9 1458 ✓ DO logic 0 = N/O
1 = N/C
0
P5.10 1331 ✓ RO1 logic Like P5.9 0
P5.11 1332 ✓ RO2 logic Like P5.9 0
P5.12 1459 ✓ DO on delay 0.00 – 320.00s 0.00
P5.13 1460 ✓ DO off delay 0.00 – 320.00s 0.00
P5.14 1461 ✓ RO1 switch-on
delay
0.00 – 320.00s 0.00
P5.15 1424 ✓ RO1 off delay 0.00 – 320.00s 0.00
P5.16 1425 ✓ RO2 switch-on
delay
0.00 – 320.00s 0.00
P5.17 1426 ✓ RO2 off delay 0.00 – 320.00s 0.00
