Chapter 12 Appendix D: Specifications
This appendix contains information describing the serial RJ−45 pinouts (Table 10) and
the serial RJ−11 (Table 11).
Table 10. RJ−45 PIN/Signal Definition
Pin No. Signal Direction Description
1 DTR Output Reserved
2 GND  Signal Ground
3 +5V  Power for CIM
4 RX Input Receive Data (Data in)
5 TX Output Transmit Data (Data out)
6 N/C N/C No Connection
7 GND  Signal Ground
8 DCD Input Reserved
Table 11. RJ−11 PIN/Signal Definition
Pin No. Signal Direction Description
1 +5V  Power
(500mA, fuse−protected)
2 GND  Signal Ground
3 RS485 (Data +) bidirectional Data Line +
4 RS485 (Data −) bidirectional Data Line −
5 GND  Signal Ground
6 1−wire  
