USING THE WEB INTERFACE
EATON Managed ePDUt User’s Guide S 164201xxx Rev 1 DRAFT 10−OCT−2008
64
About Policies
The diagram below illustrates the way policies associate events with destinations. In
this example, five events and two policies are defined.
S Events 1 and 2 are associated with the Red policy. This means they trigger an
email message to an administrator and an SNMP trap.
S Events 3, 4, and 5 are associated with the Syslog policy. They trigger entries in the
event log, but do not send email messages or traps.
Policies
Red
Syslog
Destinations
Event Log
eMail
SNMP
Switch Outlets
Events
1
2
3
4
5
Figure 59. Policies
Display Existing Policies
To display a list of existing policies:
1. Select Alerts, and then select Alert Policies. The Alert Policies page displays. It
lists each policy and shows their destinations (see Figure 60).
Figure 60. Alert Policies Page
2. You can modify or delete a policy by clicking the corresponding button next to
the policy. You can add a new policy and configure alerts and destinations by
clicking the appropriate link.
