Eaton
®
Power Xpert
®
9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 4-1
Chapter 4 UPS System Installation
4.1 Preliminary Installation Information
WARNING
Installation should be performed only by qualified personnel.
AVERTISSEMENT!
L’installation ne doit être effectuée que par du personnel qualifié.
Refer to the following while installing the UPS system:
l
Chapter 3 for cabinet dimensions, equipment weight, wiring and terminal data, and installation notes.
l
Do not tilt the cabinets more than 10° during installation.
l
Remove the conduit landing plates to add conduit landing holes as required. Plate material is 16 gauge steel
(1.5 mm/0.06” thick).
l
If perforated floor tiles are required for ventilation, place them in front of the UPS.
4.2 Unloading the ISBM with UPM Section from the Pallet
The ISBM cabinets with a UPM or UPMs are joined and bolted to a wooden pallet supported by wood skids.
They are referred to as the UPS.
WARNING
The ISBM with UPM or UPMs section is heavy (see Table 3-1). If unpacking and unloading
instructions are not closely followed, the cabinets may tip and cause serious injury.
AVERTISSEMENT!
Les sections de l’onduleur sont lourdes (voir le tableau 3-1). Suivre attentivement les instructions
de déchargement et de déballage pour éviter de renverser les armoires, ce qui pourrait causer de
graves blessures.
CAUTION
l
Do not tilt cabinets more than 10° from vertical.
l
Lift the cabinets only with a forklift or damage may occur.
