Eaton PowerXL DM1 Series - Catalog Number System; Figure 2. Catalog Numbering System

2
Chapter 1—PowerXL DM1 Series overview
POWERXL SERIES VFDS MN040060EN—September 2020 www.eaton.com
Catalog number system
Figure 2 is for illustrative purposes only, please select a part
number from the table below.
Figure 2. Catalog numbering system.
Series Power part Options Region
D M 1 - 3 4 4 D 3 E B - S 2 0 S -
Basic naming
D = Drive
Series
M = Machinery
Product generation
1 = First generation
2 = Second generation
Phase reference
3 = 3
~
INPUT / 3
~
OUTPUT
1 = 1
~
INPUT / 3
~
OUTPUT
Input / output voltage rating
1 = 115 V (100 - 120 V + 10%/-15%)
2 = 230 V (200 - 240 V + 10%/-15%)
4 = 400 V (380 - 480 V + 10%/-15%)
5 = 575 V (525 - 600 V + 10%/-15%)
Output current rating (single phase) Output current rating (three phase)
100 - 120 v 200 - 240 v 200 - 240 v 380 - 480 v 525 - 600 v
1D6 = 1.6 A, 0.18 kW, 0.25 hp 1D6 = 1.6 A, 0.18 kW, 0.25 hp 1D6 = 1.6 A, 0.18 kW, 0.25 hp 1D5 = 1.5 A, 0.37 kW, 0.50 hp 4D5 = 4.5 A, 2.20 kW, 3.00 hp
3D0 = 3.0 A, 0.37 kW, 0.50 hp 3D0 = 3.0 A, 0.37 kW, 0.50 hp 3D0 = 3.0 A, 0.37 kW, 0.50 hp 2D2 = 2.2 A, 0.75 kW, 1.00 hp 7D5 = 7.5 A, 3.00 kW, 5.00 hp
4D8 = 4.8 A, 0.75 kW, 1.00 hp 4D8 = 4.8 A, 0.75 kW, 1.00 hp 4D8 = 4.8 A, 0.75 kW, 1.00 hp 4D3 = 4.3 A, 1.50 kW, 2.00 hp 010 = 10.0 A, 5.50 kW, 7.50 hp
6D9 = 6.9 A, 1.10 kW, 1.50 hp 7D8 = 7.8 A, 1.50 kW, 2.00 hp 7D8 = 7.8 A, 1.50 kW, 2.00 hp 5D6 = 5.6 A, 2.20 kW, 3.00 hp 013 = 13.5 A, 7.50 kW, 10.00 hp
011 = 11.0 A, 2.20 kW, 3.00 hp 011 = 11.0 A, 2.20 kW, 3.00 hp 7D6 = 7.6 A, 3.00 kW, 5.00 hp 018 = 18.0 A, 11.00 kW, 15.00 hp
017 = 17.5 A, 4.00 kW, 5.00 hp 017 = 17.5 A, 4.00 kW, 5.00 hp 012 = 12.0 A, 5.50 kW, 7.50 hp 022 = 22.0 A, 15.00 kW, 20.00 hp
025 = 25.3 A, 5.50 kW, 7.50 hp 016 = 16.0 A, 7.50 kW, 10.00 hp
032 = 32.2 A, 7.50 kW, 10.00 hp 023 = 23.0 A, 11.00 kW, 15.00 hp
048 = 48.3 A, 11.00 kW, 15.00 hp 031 = 31.0 A, 15.00 kW, 20.00 hp
038 = 38.0 A, 18.50 kW, 25.00 hp
Shading legend
FR1 FR2 FR3 FR4
DM1 option cards list:
1) DXM-NET-PROFIBUS : DM1 PROFIBUS communications card
2) DXM-NET-CANOPEN : DM1 CANOPEN communication card
3) DXG-NET-SWD-IP20 DM1/DG1: Smartwire communication card and module IP20
4) DXG-NET-SWD-IP54 DM1/DG1 : Smartwire communication card and module IP54
Internal EMC filter
E = Internal EMC filter
N = No EMC filter
Internal brake chopper
N = No brake chopper
B = Brake chopper
Display options
N = No display
S = Multi-segment LCD display
(DM1 Pro)
IP rating
20 = IP20
Control options
B = No STO, No Ethernet communications, and
No option cards
S = STO SIL2 and Ethernet I/P, Modbus TCP
onboard, and Option card port (DM1 Pro)
Region
Blank = US
EM = EMEA
AP = APAC
