Chapter 1—PowerXL DM1 Series overview
POWERXL SERIES VFDS MN040060EN—September 2020 www.eaton.com
Power ratings and product selection
Table 2. PowerXL DM1 Series drives 230 V 3-phase input.
Constant torque (CT)/high overload (I
H
) Variable torque (VT)/low overload (I
L
)
Frame
size
230 V, 50 Hz
kWrating
230 V, 60 Hz
hp
Current
A
230 V, 50 Hz
kW rating
230 V, 60 Hz
hp
Current
A
No EMC
Catalog number
With EMC
Catalog number
FR1 0.18 0.25 1.6 0.37 0.5 2.5 DM1-321D6NB-N20B DM1-321D6EB-N20B
0.37 0.5 3 0.75 1 4.8 DM1-323D0NB-N20B DM1-323D0EB-N20B
0.75 1 4.8 1.5 2 7.8 DM1-324D8NB-N20B DM1-324D8EB-N20B
1.5 2 7.8 2.2 3 11 DM1-327D8NB-N20B DM1-327D8EB-N20B
FR2 2.2 3 11 4 5 17.5 DM1-32011NB-N20B DM1-32011EB-N20B
4 5 17.5 5.5 7.5 25.3 DM1-32017NB-N20B DM1-32017EB-N20B
FR3 5.5 7.5 25.3 7.5 10 32.2 DM1-32025NB-N20B DM1-32025EB-N20B
FR4 7.5 10 32.2 11 15 48.3 DM1-32032NB-N20B DM1-32032EB-N20B
11 15 48.3 15 20 62.1 DM1-32048NB-N20B DM1-32048EB-N20B
Table 3. PowerXL DM1 Series drives 480 V 3-phase input.
Constant torque (CT)/high overload (I
H
) Variable torque (VT)/low overload (I
L
)
Frame
size
480 V, 50 Hz
kWrating
480 V, 60 Hz
hp
Current
A
480 V, 50 Hz
kW rating
480 V, 60 Hz
hp
Current
A
No EMC
Catalog number
With EMC
Catalog number
FR1 0.37 0.5 1.5 0.75 1 2.2 DM1-341D5NB-N20B DM1-341D5EB-N20B
0.75 1 2.2 1.5 2 4.3 DM1-342D2NB-N20B DM1-342D2EB-N20B
1.5 2 4.3 2.2 3 5.6 DM1-344D3NB-N20B DM1-344D3EB-N20B
2.2 3 5.6 3 5 7.6 DM1-345D6NB-N20B DM1-345D6EB-N20B
FR2 3 5 7.6 5.5 7.5 12 DM1-347D6NB-N20B DM1-347D6EB-N20B
5.5 7.5 12 7.5 10 16 DM1-34012NB-N20B DM1-34012EB-N20B
7.5 10 16 11 15 23 DM1-34016NB-N20B DM1-34016EB-N20B
FR3 11 15 23 15 20 31 DM1-34023NB-N20B DM1-34023EB-N20B
FR4 15 20 31 18.5 25 38 DM1-34031NB-N20B DM1-34031EB-N20B
18.5 25 38 22 30 46 DM1-34038NB-N20B DM1-34038EB-N20B
Table 4. PowerXL DM1 PRO Series drives 115 V single phase input.
Constant torque (CT)/high overload (I
H
) Variable torque (VT)/low overload (I
L
)
Frame
size
230 V, 50 Hz
kWrating
230 V, 60 Hz
hp
Current
A
230 V, 50 Hz
kW rating
230 V, 60 Hz
hp
Current
A
No EMC
Catalog number
With EMC
Catalog number
FR1 0.18 0.25 1.6 0.37 0.5 2.5 DM1-111D6NB-S20S DM1-111D6EB-S20S
0.37 0.5 3 0.75 1 4.8 DM1-113D0NB-S20S DM1-113D0EB-S20S
FR2 0.75 1 4.8 1.1 1.5 6.9 DM1-114D8NB-S20S DM1-114D8EB-S20S
1.1 1.5 6.9 1.5 2 7.8 DM1-116D9NB-S20S DM1-116D9EB-S20S
