Appendix B—Installation guidelines
POWERXL SERIES VFDS MN040060EN—September 2020 www.eaton.com
Table 35. Power factor and THDi.
Input
line
voltage
(V)
Load
torque
230V FR1 230V FR2 230V FR3 230V FR4
Total
power
factor
THDi
Total
power
factor
THDi
Total
power
factor
THDi
Total
power
factor
THDi
Phase
R
Phase
S
Phase
T
Phase
R
Phase
S
Phase
T
Phase
R
Phase
S
Phase
T
Phase
R
Phase
S
Phase
T
176.8 25% 0.82 65% 66% 65% 0.86 52% 53% 53% 0.71 97% 94% 94% 0.68 105% 103% 102%
50% 0.89 45% 46% 46% 0.91 37% 38% 37% 0.76 82% 80% 79% 0.73 92% 91% 90%
75% 0.91 37% 38% 39% 0.92 31% 32% 32% 0.78 76% 74% 74% 0.76 84% 83% 83%
100% 0.92 33% 33% 34% 0.93 26% 28% 27% 0.81 68% 66% 65% 0.79 73% 74% 73%
208 25% 0.80 70% 69% 68% 0.86 54% 54% 54% 0.70 97% 93% 94% 0.63 113% 109% 111%
50% 0.86 52% 52% 52% 0.91 37% 39% 38% 0.74 87% 84% 84% 0.73 94% 91% 91%
75% 0.90 42% 42% 43% 0.92 31% 33% 31% 0.77 79% 77% 77% 0.75 85% 83% 84%
100% 0.91 37% 37% 37% 0.93 28% 30% 28% 0.79 72% 71% 70% 0.77 79% 78% 78%
230 25% 0.78 74% 73% 72% 0.83 62% 63% 62% 0.68 102% 98% 100% 0.66 109% 106% 104%
50% 0.85 58% 57% 55% 0.88 47% 48% 47% 0.74 89% 86% 86% 0.70 100% 98% 97%
75% 0.89 45% 45% 46% 0.92 34% 36% 34% 0.77 81% 79% 78% 0.73 91% 89% 88%
100% 0.90 39% 40% 40% 0.93 29% 31% 30% 0.79 74% 71% 71% 0.76 81% 81% 81%
264 25% 0.77 79% 77% 76% 0.83 61% 61% 61% 0.66 106% 101% 102% 0.67 108% 104% 107%
50% 0.82 64% 64% 63% 0.90 42% 43% 41% 0.72 94% 91% 91% 0.71 98% 93% 95%
75% 0.87 50% 50% 50% 0.91 37% 39% 37% 0.75 84% 82% 81% 0.75 87% 84% 85%
100% 0.90 43% 43% 43% 0.92 32% 35% 32% 0.77 80% 78% 77% 0.76 84% 81% 82%
Input
line
voltage
(V)
Load
torque
480V FR1 480V FR2 480V FR3 480V FR4
Total
power
factor
THDi
Total
power
factor
THDi
Total
power
factor
THDi
Total
power
factor
THDi
Phase
R
Phase
S
Phase
T
Phase
R
Phase
S
Phase
T
Phase
R
Phase
S
Phase
T
Phase
R
Phase
S
Phase
T
323 0% 0.38 184% 159% 178% 0.45 177% 150% 157% 0.74 89% 85% 89% 0.78 77% 73% 74%
50% 0.63 119% 118% 116% 0.67 106% 106% 106% 0.79 74% 70% 73% 0.85 59% 54% 56%
75% 0.65 114% 113% 112% 0.71 96% 96% 96% 0.83 61% 58% 63% 0.89 47% 43% 45%
100% 0.67 106% 104% 103% 0.71 95% 95% 95% 0.87 52% 48% 52% 0.91 41% 38% 40%
380 0% 0.35 186% 173% 193% 0.41 190% 171% 176% 0.73 93% 88% 93% 0.75 85% 80% 82%
50% 0.59 134% 131% 132% 0.64 116% 115% 116% 0.77 81% 77% 80% 0.80 70% 67% 68%
75% 0.61 127% 124% 123% 0.66 112% 111% 112% 0.80 72% 68% 72% 0.86 56% 52% 52%
100% 0.66 109% 106% 105% 0.69 103% 102% 102% 0.83 62% 58% 63% 0.89 47% 45% 46%
480 0% 0.35 157% 144% 163% 0.40 172% 160% 165% 0.72 95% 91% 96% 0.73 90% 84% 87%
50% 0.62 123% 118% 120% 0.66 110% 109% 111% 0.77 80% 76% 80% 0.81 69% 65% 68%
75% 0.65 113% 110% 110% 0.69 102% 102% 102% 0.80 72% 69% 71% 0.86 55% 50% 53%
100% 0.69 101% 98% 97% 0.71 95% 95% 95% 0.83 63% 58% 63% 0.89 46% 43% 45%
528 0% 0.32 181% 152% 161% 0.39 167% 152% 176% 0.71 98% 92% 97% 0.74 87% 82% 85%
50% 0.64 116% 112% 109% 0.66 112% 110% 111% 0.76 83% 79% 82% 0.80 71% 67% 69%
75% 0.66 111% 107% 107% 0.68 105% 104% 104% 0.79 73% 70% 73% 0.85 58% 52% 56%
100% 0.67 108% 104% 104% 0.71 94% 95% 94% 0.82 65% 61% 65% 0.88 49% 45% 48%
