Chapter 1—PowerXL DM1 Series overview
POWERXL SERIES VFDS MN040060EN—September 2020 www.eaton.com
Table 8. PowerXL DM1 PRO Series drives 575 V 3-phase input.
Constant torque (CT)/high overload (I
H
) Variable torque (VT)/low overload (I
L
)
Frame
size
575 V, 50 Hz
kWrating
575 V, 60 Hz
hp
Current
A
575 V, 50 Hz
kW rating
575 V, 60 Hz
hp
Current
A
No EMC
Catalog number
FR2 2.2 3 4.5 3 5 7.5 DM1-354D5NB-S20S
3 5 7.5 5.5 7.5 10 DM1-357D5NB-S20S
5.5 7.5 10 7.5 10 13.5 DM1-35010NB-S20S
FR3 7.5 10 13.5 11 15 18 DM1-35013NB-S20S
FR4 11 15 18 15 20 22 DM1-35018NB-S20S
15 20 22 18.5 25 27 DM1-35022NB-S20S
Accessories
Table 9. PowerXL Series - DM1 NEMA 1 conversion kits.
Description Catalog number
DM1 FR1 NEMA 1 kit DXM-ACC-FR1N1KIT
DM1 FR2 NEMA 1 kit DXM-ACC-FR2N1KIT
DM1 FR3 NEMA 1 kit DXM-ACC-FR3N1KIT
DM1 FR4 NEMA 1 kit DXM-ACC-FR4N1KIT
DXM-ACC-FR1N1KIT-PLENUM DM1 FR1 Plenum Rated NEMA 1 Kit
DXM-ACC-FR2N1KIT-PLENUM DM1 FR2 Plenum Rated NEMA 1 Kit
DXM-ACC-FR3N1KIT-PLENUM DM1 FR3 Plenum Rated NEMA 1 Kit
DXM-ACC-FR4N1KIT-PLENUM DM1 FR4 Plenum Rated NEMA 1 Kit
Table 10. PowerXL Series - DM1 communication card kits.
Description Catalog number
DG1/DM1 smartwire communication card and module IP20 DXG-NET-SWD-IP20
DG1/DM1 smartwire communication card and module IP54 DXG-NET-SWD-IP54
DM1 profibus communications card DXM-NET-PROFIBUS
DM1 canopen communications card DXM-NET-CANOPEN
Table 11. PowerXL Series - DM1 remote keypad kits.
Description Catalog number
Remote keypad DXG-KEY-LCD
Remote keypad mounting holder DXG-KEY-HOLDER
DG1/DM1 remote keypad kit (3.0 m cable) DXG-KEY-RMTKIT
DG1/DM1 remote keypad mounting holder only bulk pack (99) DXG-KEY-HOLDER-BP
Table 12. PowerXL Series - DM1 demo units.
Description Catalog number
Demo case DM1 PRO DM1-DEMO
Table 13. PowerXpert in-control software.
Description Catalog number
PC cable DXG-CBL-PCCABLE
