14
Chapter 4—Mechanical installation
POWERXL SERIES VFDS MN040060EN—September 2020 www.eaton.com
Table 15. Approximate mounting dimensions in inches (mm).
Output rating Dimensions Weight
Input
voltage
Frame
size
Drive
catalog
number
CT/IH
current
amps
VT/IL
current
amps
D
in. (mm)
H1
in. (mm)
H2
in. (mm)
W1
in. (mm)
W2
in. (mm)
W3
in. (mm)
Ф
in. (mm) lb (kg)
380 Vac to
480 Vac
50/60 Hz
3-phase
FR1 DM1-341D5 1.5 2.2 7.0 9 (180) 5.98 (152) 5.51 (140) 2.83 (72) 2.26 (57.5) 2.26 (57.5) 0.20 (5.2) 2.6 (1.2)
DM1-342D2 2.2 4.3 7.09 (18 0) 5.98 (152) 5.51 (140) 2.83 (72) 2.26 (57.5) 2.26 (57.5) 0.20 (5.2) 2.6 (1.2)
DM1-344D3 4.3 5.6 7.09 (18 0) 5.98 (152) 5.51 (140) 2.83 (72) 2.26 (57.5) 2.26 (57.5) 0.20 (5.2) 2.6 (1.2)
DM1-345D6 5.6 7.6 7.09 (180) 5.98 (152) 5.51 (140) 2.83 (72) 2.26 (57.5) 2.26 (57.5) 0.20 (5.2) 2.6 (1.2)
FR2 DM1-347D6 7.6 12 7.09 (18 0) 8.66 (220) 8.15 (207) 4.29 (109) 3.56 (90.5) 3.56 (90.5) 0.22 (5.5) 5.7 (2.6)
DM1-34012 12 16 7.09 (180) 8.66 (220) 8.15 (207) 4.29 (109) 3.56 (90.5) 3.56 (90.5) 0.22 (5.5) 5.7 (2.6)
DM1-34016 16 23 7.09 (18 0) 8.66 (220) 8.15 (207) 4.29 (109) 3.56 (90.5) 3.56 (90.5) 0.22 (5.5) 5.7 (2.6)
FR3 DM1-34023 23 31 7.09 (18 0) 10.24 (260) 9.72 (247) 5.12 (130) 4.57 (116) 4.57 (116) 0.22 (5.5) 8.2 (3.7)
FR4 DM1-34031 31 38 7.6 8 (195) 11.81 (300) 11.06 (281) 7.24 (184) 6.3 (160) 6.3 (160) 0.24 (6) 13.9 (6.3)
DM1-34038 38 46 7.68 (195) 11.81 (300) 11.06 (281) 7.24 (184) 6.3 (160) 6.3 (160) 0.24 (6) 13.9 (6.3)
525 Vac to
600 Vac
50/60 Hz
3-phase
FR2 DM1-354D5 4.5 7.5 7.0 9 (180) 8.66 (220) 8.15 (207) 4.29 (109) 3.56 (90.5) 3.56 (90.5) 0.22 (5.5) 5.7 (2.6)
DM1-357D5 7.5 10 7.0 9 (180) 8.66 (220) 8.15 (207) 4.29 (109) 3.56 (90.5) 3.56 (90.5) 0.22 (5.5) 5.7 (2.6)
DM1-35010 10 13.5 7.0 9 (180) 8.66 (220) 8.15 (207) 4.29 (109) 3.56 (90.5) 3.56 (90.5) 0.22 (5.5) 5.7 (2.6)
FR3 DM1-35013 13.5 18 7.09 (180) 10.24 (260) 9.72 (247) 5.12 (130) 4.57 (116) 4.57 (116) 0.22 (5.5) 8.2 (3.7)
FR4 DM1-35018 18 22 7.6 8 (195) 11.81 (300) 11.06 (281) 7.24 (184) 6.3 (160) 6.3 (160) 0.24 (6) 13.9 (6.3)
DM1-35022 22 27 7.6 8 (195) 11.81 (300) 11.06 (281) 7.24 (184) 6.3 (160) 6.3 (160) 0.24 (6) 13.9 (6.3)
(continued).
