Communications
Copyright © 2007-2018 Eaton Corporation. All Rights Reserved.
IPN 997-00012-03 B2 Issue B2 July 2018
109
Trap Repeat
Trap Repeat Rate
Enable trap repeat if the network is not reliable
enough to ensure that traps get through the first time.
Enable Heartbeat Trap
Heartbeat Trap Period
The heatbeat trap (if enabled) is sent periodically to
tell the NMS that the SC300 is still “alive” and
communicating.
For each SNMP trap receiver (up to 8) , configure the following parameters:
Parameter Configuration Guidelines
Name Type the name of the SNMP trap receiver (20 bytes maximum).
This allows 20 ASCII characters, but less for languages with multi-byte
characters.
Level SNMP Trap Level – controls reporting of specific events for each receiver:
• Select All Alarms And Warnings to receive Critical, Major and Minor
alarms, and Warnings. (Typically Warnings are status messages such
as Equalize Active.)
• Select Minor And Above to receive Critical, Major and Minor alarms.
• Select Major And Above to receive only Critical and Major alarms.
• Select Critical Only to receive only Critical alarms.
• Select Disabled to disable notifications to the receiver.
To prevent an SNMP Trap for an individual alarm, set Send Trap to False
in the alarm's configuration.
IP Address IP address of the trap receiver assigned by the network administrator.
Port The default setting is 162. Do not change this setting, unless requested by
the network administrator.
Trap
Community
A form of password used with SNMP V1 and V2c. Use public, unless the
network administrator has assigned a new password.
Mode Select:
• Normal Traps for sending traps to any network management system,
except PowerManagerII
• Acknowledged Summary Trap for sending traps to PowerManagerII
only
To change SNMP trap sending options by trap source
To make the SC300 send a trap only on an alarm activation or deactivation, or to stop the SC300
sending any traps when a particular alarm occurs:
1 Go to the Send Trap setting for that particular alarm. Send trap settings are present in the Alarm
States Table, Analog Input Alarms tables, and Digital input alarms table.
2 Change the setting from Both to :
• None for no traps sent of that alarm
• Activation, for traps sent only when the alarm becomes active.
• Deactivation, for traps sent only when the alarm becomes inactive.
