SC300 Operation
Copyright © 2007-2018 Eaton Corporation. All Rights Reserved.
IPN 997-00012-03 B2 Issue B2 July 2018
19
Generic System Types
If the user does not have a suitable configuration file for a new SC300, or he/she needs to
change the operating voltage of a system, then the Generic System Types may be used as a
starting point.
To select a Generic System Type, in web go to Identity > Software and select an appropriate
type.
Suitable settings are then loaded into the SC300.
• Master Configuration takes settings back to the last configuration loaded by web or DCTools.
This is useful where settings have been incorrectly changed.
• Factory wipes settings and resets to the normal ex-factory settings.
• APS48V / APS24V / EPS48V LVD and EPS48V only load settings that are specific to that voltage
or system type. Other settings are left unchanged.
The settings loaded using Generic System Type may not be suitable for all systems. Where
possible, obtain the appropriate configuration file.
After selecting a Generic System Type, check system operation.
If the original configuration is corrupt or unknown, this procedure should be followed:
1. Load the Factory configuration
2. Load the appropriate Generic system type.
These are the currently available Generic System Types:
Generic System Type Action
Unknown No effect; does not change settings.
Factory Loads the standard factory settings, except that IP addresses
are not changed.
Master Config Re-loads the last configuration file loaded by DCTools or
web and saved by the SC300.
APS48V Loads standard 48V positive earth settings.
Set for 1 LVD only.
APS24V Loads standard 24V negative earth settings
Set for 1 LVD only.
EPS 48V LVD Loads a standard 48V positive earth settings.
Includes an LVD.
EPS48V Loads a standard 48V positive earth settings.
No LVD.
