Invert:
-
Trigger:
Level
► To Create an AC Low Smart Alarm
1 Configure a Smart Alarm with the following parameter settings:
Name:
AC Low
Operator:
OR
Severity:
Minor (or a different severity if required).
Set other parameters as required (see details on page 62).
2 Configure a System Values Source with the following parameter settings:
SA Num:
The number of the Smart Alarm configured in step 1.
Status:
Enabled
System Value:
AC Voltage
Threshold Type:
Low
Threshold:
185 (or a different value if required)
Hysteresis:
5 (or a different value if required)
Invert:
-
Trigger:
Level
Batteries
The following information is available about the batteries connected to the dc power system.
See also Battery Time Remaining on page 73.
Parameter Description Where to find:
Battery Charge
State
Charge - the battery current is above the Battery
State Threshold.
Discharge - the battery current is below -1 *
Battery State Threshold.
Float - the battery current is between ± Battery
State Threshold.
Unavailable - the battery current is not
available.
 See SC300 or Web displays ??? or N/A on
page 123.
SC300: Battery > Battery
DCTools/Web: Batteries
Battery
Temperature
The temperature measured by the battery
temperature sensor.
Ah Discharged The current level of battery discharge.
See also Reset Ah Discharged on page 76.
