SC300 Operation
Copyright © 2007-2018 Eaton Corporation. All Rights Reserved.
IPN 997-00012-03 B2 Issue B2 July 2018
9
The display will appear some time before rack control starts and remote communications is
enabled. This is a different sequence to the SC200.
Main Screen Shortcut Keys
Key Function
From the Main Screen go directly to the Alarms screen.
From the Main Screen go directly to the Settings screen.
From the Main Screen go directly to the Control Processes screen.
From the Main Screen go directly to the Analogs screen.
SC300 Operation using the Keypad and Screen
1.
LCD
2.
Soft key 1 label
3.
Soft key 1
4.
Navigation keys (Up - Down -
Left - Right)
5.
Soft key 2
Soft key 2 label
To Next Page
