CHAIN BRAKE SYSTEM
CS-2511TES
251Ts, 251TCs
45
6 CHAIN BRAKE SYSTEM
(B)
(A) Brake lever
(B) Bolt (M5)
(C) Torsion spring
(D) Collar
(E) Sprocket guard
(F) Collar
(G) Brake connector
(H) Pin
(J) Brake band
(K) Spacer
(L) Compression spring
(M) Brake cover
(N) Bolt (M4)
(C)
(D)
(E)
(G)
(J)
(A)
(K)
(L)
(M)
6-1 Replacingbrakeleverandtorsionspring
{Disassembling}
1. Remove starter assembly and sprocket guard
from the unit.
2. Remove bolt (A), chain catcher (B), and sprock-
et guard plate (C)
A
C
B
(F)
(H)
(N)
