Section 9. Climate Control Eclipse 5OO Systems Manual
Copyright © — Eclipse Aviation Corporation
202 Version 2.0 April 2007
Left and right bleed air available. Left bleed air available. Right bleed air available
Figure 130. Automatic Isolation/Cabin Shutoff Valve Operation
Cabin/Cockpit Cockpit Only
Figure 131. Manual Isolation Valve/Cabin Shutoff Valve Operation
(AIR DISTR Line Select Key)
NOTE:
In the third Line Select key position (AUTO), air distribution is controlled by the
ACS or the Air Source Switch.
