Section 9. Climate Control Eclipse 5OO Systems Manual
Copyright © — Eclipse Aviation Corporation
Version 2.0 April 2007 203
Figure 132. Manual Isolation Valve/Cabin Shutoff Valve Operation
(AIR SOURCE Switch)
NOTE:
When the AIR SOURCE switch is in any position other than AUTO, the AIR
DISTR Line Select key reverts to the AUTO position.
