Section 10. Electrical Eclipse 5OO Systems Manual
Copyright © — Eclipse Aviation Corporation
220 Version 2.0 April 2007
10.3 Limitations and Specifications
Batteries
Nominal voltage (each battery) 24 VDC
Battery capacity (each battery) 22 amp-hours
Minimum voltage for battery start 23 VDC
Starter/Generators
Regulated Output voltage (each generator) 28.5 VDC
Maximum continuous output current (each generator) 200 amps
External Power
Maximum voltage 29 VDC
Minimum voltage (45 seconds) 24 VDC
Minimum voltage (any duration) 10 VDC
The External Power Contactor automatically opens if the polarity is wrong or if the
voltage is out of limits:
Greater than 29 volts at any time
Aircraft current draw greater than 400A
External Power current draw from aircraft greater than 5 A
Less than 24 volts for longer than 45 seconds, or
Less than 10 volts at any time.
