Section 14. Primary Flight Display (PFD) Eclipse 5OO Systems Manual
Copyright © — Eclipse Aviation Corporation
308 Version 2.0 April 2007
Figure 199. Inner Marker Display on PFD
If an ILS or localizer is not selected or an ILS or localizer approach is not loaded
in the FMS, the marker beacon receiver sensitivity is automatically set to HI and
the following signal is detected and displayed:
Airway Marker ........................................................White display labeled “AM.”
