Section 15. Multi Function Display (MFD) Eclipse 5OO Systems Manual
Copyright © — Eclipse Aviation Corporation
370 Version 2.0 April 2007
AURAL ALERTING
Aural alerting is provided through on-side headset audio and cockpit speakers for
various aircraft conditions and are listed in priority based on action required by flight
crew.
NOTE:
Aural alerting is routed through the PFD audio system. Should one PFD fail, the
pilot must select the cross-side PFD using the COM SOURCE select to retain
aural alerting though the headset.
Stall Warning Alert
⎯ CONDITION — Aircraft approaching stall.
⎯ AUDIO — Voice message, “Stall, Stall!”
⎯ VISUAL — “STALL” text appears in red on ADI and Master Warning Light
illuminates.
Master Warning
⎯ CONDITION — Alert associated with red warning level CAS messages
⎯ AUDIO — Master warning alert tone
⎯ VISUAL — Warning light on autopilot control panel illuminates and CAS
message appears on MFD. The warning light stays on until the condition
goes away or the master warning button is pressed by the pilot. The CAS
message remains until the condition goes away or the checklist has been
completed and the corrective action accomplished.
Cabin Altitude
⎯ CONDITION — Cabin altitude exceeds 12,750 feet
⎯ AUDIO — Voice message, “Mask on Descend!”
⎯ VISUAL — NONE
NOTE:
At 8,750 ft cabin altitude a CABIN ALTITUDE caution message appears
along with the caution alert tone and at 10,000 ft cabin altitude a CABIN
ALTITUDE warning message appears along with the caution alert tone.
Autopilot Disconnect
⎯ CONDITION — Autopilot disconnected
⎯ AUDIO — Calvary charge alert tone
⎯ VISUAL — Pulsing amber text “AP DISC” appears on the PFD below the
FMA line. A second press of the autopilot disconnect pushbutton on the
sidestick causes the aural tone and “AP DISC” message to disappear
simultaneously.
