Section 5. Oxygen Eclipse 5OO Systems Manual
Copyright © — Eclipse Aviation Corporation
Version 2.0 April 2007 77
Figure 50. Cockpit Oxygen Pressure Gauge
5.5.6 Armrest Oxygen Panel
The pilot quick don mask oxygen hose and oxygen mask microphone are connected
via the left and right armrest panels.
Figure 51. Armrest Oxygen Panel
