ADVANCED SET-UP
In-depth information on
setting up the ETEK5.
26 ETEK5 MANUAL
THE SET-UP MODE
To enter the set-up mode, fully depress and hold the trigger and then switch on
the ETEK5. The LED should ash white. Release the trigger.
If the LED ashes red then the tournament lock is on. The set-up mode can only
be accessed if the tournament lock is off (see page 24).
Once in set-up-mode, each parameter is represented by a different colour on
the LED. Press and release the trigger to cycle through all of the parameters.
COLOUR PARAMETER RANGE
Red Preset 1 to 4
Green
Maximum ROF with BS on
(capped modes only)
4.0 to 15.0 BPS
Blue Maximum ROF with BS off 4.0 to 15.0 BPS
Purple Dwell 8.0ms to 16.0ms
Light Blue Debounce 1 to 10
To see the value of the selected parameter, push and quickly release the select
button . The value will be indicated in units (long ashes) and then tenths
(short ashes) on the LED display in the colour of the selected parameter.
E.g. A Dwell of 14.5ms would be indicated as follows:
• 14 long ashes of the purple LED
• 5 short ashes of the purple LED
A zero is indicated by no ashes. E.g. A Dwell of 11.0ms would be indicated
as follows:
• 11 long ashes of the purple LED
• 0 short ashes of the purple LED
MODIFYING A PARAMETER
You can modify a parameter as follows.
1 Ensure that you are in set-up mode.
2 Choose the parameter that you wish to modify by repeatedly pressing the
trigger until the LED turns to the parameter colour.
3 Push and hold the select button for 1 second. The LED will go off.
4 Set the units value by pulling the trigger once for each unit, the LED will
ash with each trigger pull.
5 Push and release the button to switch to the tenths value
1
.
6 Set the tenths value by pulling the trigger once for each unit, the LED will
ash with each trigger pull. DO NOT pull the trigger if the required digit is
zero
1
.
7 Push and release the button. The LED will ash three times. If the colour
is green then the value has been accepted and saved. If the colour is red
then the value has been rejected and remains unchanged.
For example to set a parameter to 14.5 when following the steps above:
• Pull the Trigger 14 times when at step 4 then press
• Pull the Trigger 5 times when at step 6 then press
To leave a parameter unchanged having already started to modify it, do not pull
the trigger for 5 seconds and the value will be rejected.
Exiting Set-up mode
To exit set-up mode, push and hold the
button until the LED turns blue.
Then release the
button, the ETEK5 will exit set-up mode and the LED will
start ashing, displaying the current BS status.
1 If the parameter does not support tenths then these steps are skipped.
