FIG 20A
ETEK5 OLED BOARD
ETEK5 MANUAL 31
SWITCHING ON
Switch on the ETEK5 by pushing and holding the button
A
. The OLED display
will show a splash screen which includes model and rmware version details.
This splash screen will remain until the button is released.
RUN SCREEN LAYOUT
During normal operation, the OLED will display the Run Screen. This screen
shows the status of the ETEK5 at a glance and a typical example of the Run
Screen is shown on the right (see gure 20A).
The left of the Run Screen shows the current ring mode of the ETEK5, in this
case UNCAPPED SEMI (see page 34 for other options). The right of the Run
Screen displays user selectable information (see page 36) which in this case is
the shot counter.
The Breech Sensor Indicator allows you to see the status of the BS at a glance.
The lock indicator shows the state of the tournament lock.
Firing mode BPS setting differs per mode, in this case it is indicated by an innity
symbol to represent the unlimited (or uncapped) ring rate.
The battery level indicator provides an indication of remaining battery life.
Breech Sensor Indicator
Firing mode
Shot count / ROF indicator
Firing mode BPS setting
Lock indicator
Battery level indicator
A
