ETEK5 OLED BOARD
34 ETEK5 MANUAL
Once the user has activated the set-up mode you can cycle through the following
menu options and make the changes described below.
1
1 Somepresetsandremodesmayonlybeavailableincertaincountriesandonsomemodelsof
the ETEK5.
PRESET
Modes may vary depending on global location and ETEK5 model.
• SEMI ∞
Uncapped Semi-Automatic: one shot per trigger pull (no rate of re cap).
• SEMI 15.0
Capped Semi-Automatic: one shot per trigger pull (15.0bps cap).
• WPBO 10.2
Capped Ramping: WPBO compliant (10.2bps cap).
• NXL 10.2
Capped Ramping: NXL compliant (10.2bps cap).
• MILL 10.2
Capped Ramping: Millennium Series compliant (10.2bps cap).
• PSP 10.2
Capped Ramping: PSP compliant (10.2bps cap).
BS ON ROF*
Maximum rate of re with Breech Sensor on.
• Available range: 4.0 - 15.0 BPS
• Default setting: 15.0 BPS
BS OFF ROF*
Maximum rate of re with Breech Sensor off.
• Available range: 4.0 - 15.0 BPS
• Default setting: 10.0 BPS
