Appendix A Advanced Protocol Parameter List
Note: Parameters are for all Serinus analyzers and
may not be applicable to an individual analyzer.
Table 5 Advanced Protocol Parameter list
# Description Notes
0 Sample / Cal Valve 0=Sample, 1=Cal/Zero
1 Cal / Zero Valve 0=Zero, 1=Cal
2 Internal Span Valve 0=Closed, 1=Open
3 Spare Valve 1 0=Closed, 1=Open
4 Spare Valve 2 0=Closed, 1=Open
5 Spare Valve 3 0=Closed, 1=Open
6 Spare Valve 4 0=Closed, 1=Open
7 NOx Measure Valve 0=NO, 1=NOx
8 NOx Bypass Valve 0=NO, 1=NOx
9 NOx Background Valve 0=Closed, 1=Open
10 Valve Sequencing 0=Off, 1=On
11 LCD Contrast Pot 0=Lightest, 255=Darkest
12 SO2 REFERENCE ZERO Gain Pot S50 Reference ZERO POT
13 CO Measure Gain Pot S30 Measure Gain Adjust
14 CO Reference Gain Pot
15 CO Test Measure Pot SEE 149. EXISTS
16 & PMT HIGH VOLTAGE Pot High Voltage Controller Pot for PMT S50 & S40
17 SO2 Lamp ADJ Pot S50 Lamp Adjust Pot
18 O3 Lamp ADJ Pot S10 Lamp Adjust Pot
19 O3 ZERO Measure Pot: Coarse S10 Signal Zero (coarse)
20 O3 ZERO Measure Pot: Fine S10 Signal Zero (fine)
21 PMT Fan Pot PMT fan speed controller Pot
22 Rear Fan Pot CHASSIS Fan speed control POT
23 PUMP SPEED Motor Driver Pot:
Fine
INTERNAL Pump speed fine POT
24 PUMP SPEED Motor Driver Pot:
Coarse
INTERNAL Pump speed coarse POT
25 Analogue input 0 SO2 REFERENCE SIGNAL
26 Analogue input 1 CO REFERENCE SIGNAL
27 Analogue input 2 O3 REFERENCE SIGNAL
28 Analogue input 3 SO2 & O3 LAMP CURRENT
29 Analogue input 4 FLOW BLOCK PRESSURE
30 Analogue input 5 CELL PRESSURE
31 Analogue input 6 AMBIENT PRESSURE
32 Analogue input 7 RAW ADC CALIBRATION INPUT
33 Analogue input 8 MFC1 NOT USED
34 Analogue input 9 CONCENTRATION DATA
35 Analogue input 10 MFC2 NOT USED
36 Analogue input 11 MFC3 NOT USED
37 Analogue input 12 EXTERNAL ANALOG INPUT 0
38 Analogue input 13 EXTERNAL ANALOG INPUT 1
