ELEMENT TYPES
Analog Input
Analog inputs are input devices connected directly to the PMU.
Below is the list of analog inputs supported by PMU.
• Switch - Active High
• Switch - Active Low
• Rotary Switch
• Analog Sensor
Head to Wiring section to see wiring diagrams for each type of analog input.
Power Output
Power Outputs are devices powered by PMU which are connected to particular output pins.
Power Output examples:
• Fuel Pump
• Fan
• Oil Pump
Every Power Output has over current, under current (both user configurable) and overheat
protection. They can be either turned on by default, controlled by function or triggered by another
element such as Analog Input
CANbus Message Object (Mob)
CANbus Message Objects are interfaces needed for data gathering from CAN Stream. They read
a particular number of frames (user defined, up to 8) starting from particular ID (also user defined)
from chosen CANbus. Maximum of 8 CANbus Message Objects can be created for each CANbus.
They also have special timeout flag which can be used to set up a different strategy if a connection
from another CAN device times out.
CANbus Input
CANbus Inputs use CANbus Message Objects to extract data from chosen frame. They are able to
read a user defined number of bits starting from user defined position, then apply offsets, division
or multiplication to the extracted data.
CANbus Keyboard
CANbus Keyboard is an element that provides communication with Keyboard. It is used to define
and handle Keyboard buttons, set their color, type etc.
Switch
You can use two types of switches:
• Latching Switch – switches between user defined number of states.
• Press Hold Switch – short press switches between high and low state, holding it triggers
third state.
