Output Pin signaling and status
PMU has an ability to signal condition of each Power Output. It is displayed on the device itself and
in PMU software. When a new Power Output is created, a special variable which represents the
status of Power Output, called output_name.status is created as well. This variable can be used to
create failsafes or conditions, to set up redundancy etc.
Status value in Client LED color Status
0 None Off
1 Green On
2 Orange Under Current
3 Red Over Current
