Using output pins in parallel
PMU allows user to connect output pins in parallel to increase current capacity. Up to three output
pins of the same amperage can be used, granting up to 75A continuous current.
PMU Client configuration example:
INERTIA SWITCH
PMU is equipped with a failsafe switch which gets triggered in case of a crash. PMU constantly
monitors its gyroscopic values and acceleration in each axis to react quickly in the worst case
scenario.
Inertia Switch
Inertia Switch immediately shuts down all Power Outputs to prevent any mishaps happening in the
event of a crash. Inertia Switch gets triggered on after exceeding acceleration threshold specified
by user. Inertia Switch can be accessed by Tree View → Inertia Switch :
Page 45
