Specification
GENERAL
Temperature Range ACEQ100 GRADE1 (-40 to 120C)
CPU 32 bits automotive, 90MIPS
Reverse polarity
protection
Yes, internal up to 16V
Operating voltage 6-22V immunity to transients according to ISO 7637
Enclosure IP65, bespoke CNC machined aluminium
Size and weight 131x112x32.5mm, 345g
Connectors 1 x 39 Automotive connector
1 x M6 stud for battery connection
PC communication CAN (Peak CAN, ECUMASTER USBCAN, Kvaser)
Multiple PMUs Up to 5 PMUs can work in tandem
OUTPUTS
10 x high side 25A output Overcurrent and overheating protection.
Outputs may be paired to increase continuous current capability.
Current and voltages measured for each output.
Inductive load clamp: Vbat - 36V
Inductive energy dissipation Ear: 460mJ
Peak current: 120A
6 x high side 15A output Overcurrent and overheating protection.
Outputs may be paired to increase continuous current capability.
Current and voltages measured for each output
Indoctive load clamp with diode to: -0.5V
Peak current: 120A
Total current output 150A continuous
Output current control step 100mA
PWM Yes, available for each 25A output
Programmable variable Duty Cycle control for each output
Separate frequency setting ranging from 4Hz to 400Hz for each output
Soft Start Yes, available for each 25A output
Low side wipers braking
output
Dedicated output with wiper braking feature.
Pin shared with output #8
Current limit: 6A
+5V monitored 5V, 500mA output for powering external sensors
