Analog Inputs 16 inputs, 10 bit resolution, 0-5V (protected), with software selectable
10K Ohm pullup and pulldowns
CAN Keypads 2 x Ecumaster keypads (4, 6, 8, 12 keys), LifeRacing PDU Keypad
OTHER
Output state indication 16 bicolor LEDs
Accelerometer/Gyroscope 3D accelerometer with 3D gyroscope for logging and crash detection
Real Time Clock Yes, super capacitor for backup power (up to 3 days)
CAN BUS
CAN interface 2 x CAN2.0 A/B
CAN standard 2.0A/B 125, 250, 500, 1000 Kbps
Input/Output Stream User defined with bit masking
Up to 48 input messages
LOGGING (PMU16DL only)
Logging Memory 256 Mbytes
Logging Speed Variable, defined per channel, up to 500Hz
PC LOGGING
Logging Speed Variable, defined per channel, up to 500Hz
FUNCTIONS
Logical Operations isTrue, isFalse, =, !=, <, <=, >, >=, AND, OR, XOR, Flash, Pulse,
Toggle, Set/Reset Latch
Number of functions 100
Number of operations 250
Update frequency 500Hz
Special functions Wipers, Blinkers
