Number
Number is simply an integer. It can be either a typed in constant or value of chosen channel.
Number is mostly used for comparison or to control Duty Cycle in Pulse Width Modulation (See
PWM section).
Function
Function is one of the most important elements. It can be used to create a set of rules, conditions
to Power on an output device. Function always evaluates to either 0 or 1. If the function is used as
control channel for a Power Output, the Power Output will be turned on if function returns 1 and
turned off if function returns 0. Functions will be explained in depth later on in Functions section.
Wipers Module
Wipers module is a separate module to control the Wipers. It consists of two Power Outputs for
slow and fast wiper speed and an Analog Input for Park Switch. To use park functionality, Output
Pin O8 is provided to use for slow wiper speed. To see the wiring instructions, head to Wiring part
of the manual.
Blinkers Module
Blinkers module is a bit like Wipers Module, it is a separate element which controls the blinkers. It
consists of two Power Outputs for left and right blinkers and needs three inputs (ie. CANbus
Keyboard) to control the Left Blinker, Right Blinker and Hazard Lights.
CANbus Export
CANbus Export allows you to broadcast (send) data to the CANbus, which then can be used by
other CAN device. For example, you can transmit the status of a Fan to other PMU or EMU Black
MANAGING ELEMENTS
Saving elements
Most elements can be saved to hard drive. To save your element, click icon on elements
toolbar and choose where you want to save it.
Loading saved elements
Elements that can be saved, can also be loaded. To load your element, click icon on elements
toolbar and choose file to load.
