Operations with state
Toggle Toggles between 0 and 1 whenever Channel triggers a signal edge.
It can be set to trigger by Rising Edge or Falling Edge
If Default State is checked, default state of the Function after device
is turned on will be 1, otherwise 0.
Toggle remembers its last state, therefore if Channel signal is lost,
Toggle will remain in the last steady state.
Set-Reset Latch Set Channel sets the Latch to 1 when a high state is detected on the
selected Channel, Reset Channel resets the Latch to 0 when a high
state is detected on the Channel selected here.
Reset has a priority, therefore if Channels both for Set and Reset are
at high level, the Latch will be reset.
If Default State is checked, default state of the Function after device
is turned on will be 1, otherwise 0.
Set-Reset Latch remembers its last state, therefore if both Channels
are at low state, Set-Reset Latch will remain in the last steady state.
Page 22
