Output
Number
Terminal Max
Current
Wire
Size
Current Name Comment
O1 38 25A
O2 39 25A
O3 26 25A
O4 13 25A
O5 12 25A
O6 11 15A
O7 10 15A
O8 9 15A (wipers)
O9 5 15A
O10 4 15A
O11 3 15A
O12 2 25A
O13 1 25A
O14 14 25A
O15 27 25A
O16 28 25A
