Edge-Core ECS2100-28PP Reference Guide

Chapter 4 | System Management Commands
Event Logging
– 130 –
Example
Console#clear log
Console#
Related Commands
show log (130)
show log This command displays the log messages stored in local memory.
Syntax
show log { flash | ram }
flash - Event history stored in flash memory (i.e., permanent memory).
ram - Event history stored in temporary RAM (i.e., memory flushed on
power reset).
Default Setting
None
Command Mode
Privileged Exec
Command Usage
◆ All log messages are retained in RAM and Flash after a warm restart (i.e., power
is reset through the command interface).
◆ All log messages are retained in Flash and purged from RAM after a cold restart
(i.e., power is turned off and then on through the power source).
Example
The following example shows the event message stored in RAM.
Console#show log ram
[1] 00:01:30 2001-01-01
"VLAN 1 link-up notification."
level: 6, module: 5, function: 1, and event no.: 1
[0] 00:01:30 2001-01-01
"Unit 1, Port 1 link-up notification."
level: 6, module: 5, function: 1, and event no.: 1
Console#

Edge-Core ECS2100-28PP Specifications

General

Model	ECS2100-28PP
Type	Managed Switch
PoE	Yes
PoE Budget	370W
Switching Capacity	56 Gbps
Forwarding Rate	41.7 Mpps
MAC Address Table	16K
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Power Consumption	Max 400W
Jumbo Frame Support	9K
Management	CLI, Web, SNMP
Power Supply	AC 100-240V, 50/60Hz
Dimensions (W x D x H)	440 x 44 x 250 mm
Humidity	10% to 90% (non-condensing)
