Chapter 15

| Congestion Control Commands

Storm Control Commands

– 416 –

Example

The following shows how to configure broadcast storm control at 600 packets per

second:

Console(config)#interface ethernet 1/5

Console(config-if)#switchport broadcast packet-rate 600

Console(config-if)#

Related Commands

show interfaces switchport (365)
