SERVICE
SERVICE TOOLS & MATERIAL
The following list is considered a comprehensive tool and material list. This list however may not cover all
scenarios. Please use best judgment and practices where tooling has not been specied.
For effective repairs please have the following tool sets available:
• 1/4” or 3/8” Drive Socket Set
• SAE - 3/16”, 7/32”, 1/4”, 5/16”, 11/32”, 3/8”, 7/16”, 1/2”, 9/16”
• MM - 5, 6,7, 8, 9, 10, 11, 12, 13;
• 6” Ext Bar
• 1/4” or 3/8” Ratchet
• Wrenches
• SAE - 1/4”, 5/16”, 11/32”, 3/8”, 7/16”, 1/2”, 9/16”, 5/8”, 11/16”, 3/4”, 7/8”
• MM - 4, 5, 6, 7, 8, 9, 10, 11, 12, 13
• Hex Key Sets
• SAE - 0.050”, 1/16”, 5/64”, 3/32”, 7/64”, 1/8”, 9/64”, 5/32”, 3/16”, 7/32”, 1/4”, 5/16”, 3/8”
• MM - 1.5, 2, 2.5, 3, 4, 5, 4.5, 5, 5.5, 6, 7, 8, 9, 10
• Assortment of Screwdrivers
• SL1/8
• SL1/4
• 1/4” Round Shank Screwdriver
• PH2 x 1.5”
• PH2 x 4”
• PH2 x 12”
• Wire Snip
• Wire Stripper
• Terminal Crimper
• (2) x 6~8” Long Nose Pliers
• 6~8” Bull Nose Pliers
• (2) x 12” Pipe Wrenches
• 12” Adjustable Wrench
Instruments necessary for troubleshooting and adjustments:
• Dwyer 1213-15 Water Manometer or equivalent
• Digital Multimeter - VAC, VDC,A mA, AC μA, DC μA, Ohm, Capacitor
• Fluke 87-5
• Amprobe AM0570
General Supplies
• TFE Pipe Sealant
• 220/230 Emery Cloth
• Leak detection solution or a leak detector with a minimum 50PPM detection level
Common Wire and Connections
• Machine wire: 18AWG, UL 1015, 16 Strand, 105C, PVC
• Machine wire: 22AWG, UL 1015, 7 Strand, 105C, PVC
• Spade terminal: 1/4”, 18-22AWG (Pink/Red)
• Spade terminal: 1/4”, 14-16AWG (Blue)
• Fork terminal: #6, 18-22AWG
• Ring terminal: #10, 18-22AWG
