2.0: SPECIFICATIONS
Specifications for the 3200-XS Sub-Bottom Profiling System include electrical, mechanical, and
environmental characteristics for the Rack Mount Topside, the SB-424, SB-216S and SB-512i Tow Vehicles,
and the Tow Cable.
NOTE: All specifications are subject to change without notice.
2.1 3200 Rack Mount Processor
The Rack Mount processor is made up of a processing unit and power amplifier enclosed in a 19-inch rack.
CAUTION!
The Deck Unit is application specific. It should not be used for purposes
other than that for which it was intended.
2.1.1 Rack Mount General Specifications
The general specifications for the 3200-XS Rack Mount Processor are shown in TABLE 2-1.
SPECIFICATION VALUE
Operating temperature
0-40°C (32°-104°F)
Operating humidity
5-95% relative
Vibration
Normal ship environment
Weight
51 kg (112 lb)
Enclosure type
Portable aluminum 19-in rack type enclosure
Enclosure size
49.5 cm (19.5 in.) W
54.6 cm (21.5 in.) H
33.0 cm (13.0 in.) D
Shipping container size
71 cm (28.0 in.) W
79 cm (31.0 in.) H
109 cm (43.0 in.) D
Shipping weight
93 kg (205 lbs)
Input Power Requirement
SB-424 Towfish – 195 W
SB-216 Towfish – 264 W
SB-512i Towfish – 300 W
Table 2-1: Rack Mount General Specifications
