5-1
5.0: TROUBLESHOOTING
Should some operational or performance problems occur with the 3200-XS Sub-Bottom Profiling System,
it may be possible to correct them using the troubleshooting guide provided in T
ABLE 5-1. This
troubleshooting guide identifies some symptoms that could occur and presents one or more possible
causes, along with the recommended corrective action, for each. When using the troubleshooting guide,
perform the corrective action for any given symptom in the order of possible causes, which generally
corresponds to the degree of troubleshooting difficulty, from the simple to the more complex.
Before proceeding with any corrective action, verify the following:
• The topside is plugged into an appropriate power source (see 3.2:
POWER REQUIREMENTS)
• The AC cables inside the Deck Unit are plugged into the 3200-XS Topside Processor and the Power
Amplifier and to the AC power outlet
• The 3200-XS Topside Processor and the Power Amplifier are switched on
NOTE: Be sure to also verify that all the cables in the topside and the tow
vehicle are properly mated and are not loose or damaged. Most causes
of operational or performance problems are a result of poor connection.
