3-1
3.0: SETUP AND ACTIVATION
Setup and test of the EdgeTech 3200-XS Sub-Bottom Profiling System involves:
1. Unpacking, inspecting, and connecting the system components
2. Connecting a navigation system
3. Activating the system
4. Verifying operation using the EdgeTech DISCOVER Sub-Bottom software
This section provides instructions on how to perform these tasks, as well as information on how to deploy
and tow the tow vehicle.
3.1 Unpacking and Inspection
The rack mount topside; SB-424, SB-216S, or SB-512i Tow Vehicle are shipped in separate, reusable,
heavy-duty transport cases. Essential cables and documentation are also included. Tow cables must be
purchased separately, but are shipped in a similar manner.
Before unpacking the system components, inspect the shipping containers for any damage. Report any
damage to the carrier and to E
DGETECH CUSTOMER SERVICE, who will provide additional guidance.
If the shipping containers appear free of damage, carefully unpack the components and inspect them for
damage. If any damage is found, report it to the carrier and to E
DGETECH CUSTOMER SERVICE. Also check the
packing list and verify that all the items on the list are included. If any items are missing, immediately
contact E
DGETECH CUSTOMER SERVICE. Do not install or operate any equipment that appears to be damaged.
Although the items shipped may vary, depending on the customer requirements, the 3200-XS Sub-Bottom
Profiling System typically includes the following:
• Topside Unit and Monitor
• SB-424, SB-216S or SB-512i Tow Vehicle
• Tow Cable (length and type specified by user)
• AC power cords (2)
• Software USB
• Electronic Manuals
After unpacking the system components, be sure to safely store the shipping containers, including any
packing materials, for later use. When transporting or storing the system, all items should be packed in
their original shipping containers in the same manner in which they were originally shipped, and always
store the system in a dry environment when not in use.
