Edgetech 3200-XS - Connecting System Components

3.0: SETUP AND ACTIVATION 3-4
Figure 3-1: Front Panel of 3200-XS Rack Mount Topside
System Indicator
System Power
Hard Disk
Indicator
Hard Disk
Reset Button
CH1 Dial
(defunct)
CH2 Dial
(defunct)
Power, Bridge, &
Data Indicators
Ready
Indicators
USB
Connectors
DVD R/RW
Drive
Removable 1-TB HDD
