4-3
4.2.1 Disassembling a Tow Vehicle
To disassemble a sub-bottom tow vehicle:
1. Using the blade of a screw driver, pry out the retaining ring from the locking sleeve as shown in
F
IGURE 4-1.
Figure 4-1: Retaining Ring and Locking Sleeve Removed
2. Remove the retaining ring and the locking sleeve from the connector as shown in FIGURE 4-2.
Figure 4-2: Male Connector
