2.0 SPECIFICATIONS 2-2
2.1.2 Processor Unit Specs
The specifications for the Processing Unit within the rack mount topside are shown in TABLE 2-2.
SPECIFICATION VALUE
Mother Board
Intel I7 6700 Quad Core 3.4GHz. 8 MB Cache
Sonar Interface
Sonar Interface board (Tiger board) composed of carrier board,
Acquisition board, and Sonar board
Memory
8 GB DDR4 RAM
Hard Drives
500 GB minimum (operating system)
1 TB minimum (Removable Drive [Hot Swappable])
DVD-R/W drive
10x4x32 minimum speed
Operating system
Windows 7 64 Bit
Application software
DISCOVER Sub-Bottom
Display
High resolution 23-inch flat panel LCD monitor
Keyboard
High impact industrial
Trackball
High impact industrial
I/O ports
(4) RS-232
Front: (2) Ethernet Ports
(2) USB2
Rear: (2) USB2
(2) USB3
(2) USB3.1
Analog input
16-bit resolution, 200 kHz max sampling rate
Analog Output
16-bit resolution, 200 kHz max sampling rate
Pulse type
Full Spectrum CHIRP FM
Pulse length
5-100 ms, depending on tow vehicle and application
Bandwidth
0.5-15 kHz, depending on tow vehicle and application
Trigger in
TTL negative edge triggered
Trigger out
TTL negative edge triggered, 5ms ling pulse minimum
Sampling rate
20, 25, 40, or 50 kHz, depending on the transmit upper frequency
Acoustic power
212 dB re1 NPa @ 1 meter peak (approx.) at center frequency
Input voltage
120-220 VAC, 50/60 Hz, auto sense
Table 2-2: 3200-XS Topside Processor Specs
2.1.3 Power Amplifier
The specifications for the Power Amplifier are show in TABLE 2-5, TABLE 2-4, and TABLE 2-5.
2.1.3.1 Power Output
SPECIFICATION VALUE
2-ohm Dual (per channel)
20 mS BURST: 4,700 W
20 Hz – 20 kHz: 2,800 W
1 kHz: 2,800 W
4-ohm Dual (per channel)
3,500 W
8-ohm Dual (per channel)
1,500 W
4-ohm Bridge
5,600 W
8-ohm Bridge
6,000 W
Table 2-3: Power Amplifier Specs: Power Output
