2-12 2.0: SPECIFICATIONS
3200-XS SUB-BOTTOM SYSTEM 0004840_REV_E
2.2.1 Kevlar Reinforced Tow Cable Specifications
The general specifications for the Kevlar Reinforced Tow Cable are shown in TABLE 2-7. The 75meter length
is not the only cable option for the 3200-XS system, but it is the most popular.
SPECIFICATION VALUE
Twisted-shielded wire pairs
(1) #16 AWG
(2 ) #20 AWG
Braking strength 1600 kg (3500 lb)
Working strength 295 kg (650 lb)
Weight in air 30.8 kg/100 m (207 lb/1000 ft)
Voltage rating 600 volts
Bending radius 25.4 cm (10.0 in.) minimum
Length 75 m (245 ft) standard
Table 2-7: 75-Meter Kevlar Reinforced Tow Cable Specifications
NOTE: Cables do not come standard with the system and must be
specified upon purchase. For more information about cable options,
contact EDGETECH CUSTOMER SERVICE.
