ii
SEASTAR Hydraulics
ii
INTRODUCTION
Index
Before Operating Your Boat ........................................................ 1
Compatibility/Tools/Specifications.............................................. 2
How The System Works ............................................................. 3
Things You Need to Know .......................................................... 4
Before Starting ......................................................................... 4
System Installation Overview...................................................... 5
Specific Installation
Outboard Front Mount & HC5332............................................... 6
Side Mount & Splashwell Mount Cylinders .................................. 9
Inboard & Sterndrive ............................................................... 10
Autopilot Connection................................................................ 11
Electrical Installation ............................................................... 12
Power Purge Filling and Purging................................................ 14
Manual Filling and Purging ....................................................... 15
Troubleshooting....................................................................... 21
Accessories ............................................................................ 23
Mounting Templates ................................................................ 25
Warranty ................................................................................. 29
Before proceeding with the installation, read these instructions
thoroughly. Teleflex cannot accept responsibility for installations
where instructions have not been followed, where substitute
parts have been used, or modifications have been made to
our products. Warranty may be void if products other than
Teleflex products are used with this system.
Due to a small amount of internal hydraulic slip, a "master spoke:
or "centered" steering wheel cannot be maintained with a Hydraulic
Steering System. For best results, use an equal distance spoke
steering wheel.
DO NOT use a wire coil type trim switch with a hydraulic steering
system. Wire coil can wind up tight around the steering wheel
shaft and prevent further steering!
PRO Trim offers fingertip trim or jackplate control with a column-
mounted switch, enabling you to keep both hands on the steering
wheel and concentrate on your driving. PRO Trim PT1000 controls
trim or jackplate only. PRO Trim Dual PT2000 controls both functions.
NOTICE
WARNING
This installation manual covers
the entire, SeaStar and SeaStar
PRO PA Series. Notes are made,
when required, to cover any
differences between the part
numbers.
NOTICE
SeaStar PRO Power Assist units are to be used with SeaStar PRO
Helms ONLY!
WARNING
The following Power Assist Units are covered in this installation
manual. PA1200-2, PA1225-2 and PA1315-2.
