Owner’s Manual
1 Stainless steel blade with hinge #20141-001 (B-9x12 dimensions of tab)
2 Electromechanical Actuator #101, #101 XD, #101 XDS, #102 XD
3 Upper mounting bracket #15085-001 (116)
4 Space saver upper mounting bracket
(optional)
#50225-001 (117)
5 Lower mounting bracket #50014-001 (119)
6 RetroFit Kit bracket #15085-001 (116)
7 (Qty. 2) 5/16 #18 X 1-3/4" large hex head
bolt and 5/16
#10250 - 001
8 #123 L.E.D. Indicator Switch w/Retractor
(optional)
#15070-001 (123SC)
9 124SSR Standard solid state Tactile Switch
w/ Retractor (optional)
#15069-001 (124SSR)
10 #123 DR Dual Actuator L.E.D. Indicator
Switch w/Retractor (optional)
#15071-001 (123DRSC)
11 Shim kit (optional) #50015-002 (118S)
12 (Qty. 26) 1-1/4" (3.17 cm) stainless steel
sheet metal screw kit
#10002-001 (Kit #1)
13 (Qty. 6) 20 X 7/8" (2.22 x .63 cm)
stainless steel screws, ( Qty 6) flat washers
and (Qty. 6) 1/4" (.63 cm) lock nuts
Kit #4
Troubleshooting Guide
for Trim Tabs
Trim tabs do not work together,
independently or intermittently.
Solution Sequence:
1) I nspect fuse at fuse panel.
Replace if necessary.
2) Verify that all connections at switch
control box are tight and in place.
3) Make sure that switch assembly has a
solid ground.
4) If the actuator cables were spliced
inside the transom, inspect joint for
positive connection.
5) If, after following steps stated above,
the actuators still do not operate
properly — STOP and call the factory
for further assistance at 772-288-2662.
Additional Information
• Check electrical connections behind
switch and make sure ground wire is
in place.
• The addition of a zinc anode will deter
electrolysis. It is important that the zinc
is in contact with the trim tab blade.
• To discourage any marine growth
on tab or actuator, antifouling paint
can be applied. When applying paint
to the actuator, make sure it is fully
retracted. Do not paint the stainless
ram above the area that is exposed
when retracted.
• If tabs malfunction or tabs become
stuck in the down position while
underway, remove pin or bolt at the
lower mounting bracket.
• To reposition the actuator turn stainless
steel ram clockwise and reattach.
Trim Tab System Parts & Troubleshooting
