3-6
Selection Guide
OUTBOARD–FRONT MOUNT
Twin Engine Application Guide
REVISION DATE: ________________
NOV. 23rd 2007
MFG YEAR MODEL CYL
TIE BAR KITS
NOTES
TWIN x 1 TWIN x 2
FORCE 1985-DATE 90-150 HP HC5345 HO5008A HO5008A
HONDA 1996-DATE 75-90HP HC5345 HO6001 HO6002 See Note 3
1998-DATE 115-130HP HC5347 HO5063 HO5064 See Note 5
1998-DATE 30-50HP HC5345 HO6001 HO6002 See Note 2
2001-DATE 150HP 4-Stroke HC5345 N/A HO6002 See Note 7
2001-DATE 225HP 4-Stroke HC5345 HO6001 HO6002
2003-DATE BF135HP HC5345 HO6003 HO6002
JOHNSON/ 1977-1990 65-300HP HC5348 HO6003 HO6002
EVINRUDE
1988-1997 250-300HP V8 HC5342 HO5001A HO5030 See Note 5
1991-DATE 40-250HP HC5345 HO6003 HO6002 Inc. ETech Engines.
1996-DATE 75-250HP Ficht HC5345 HO6003 HO6002
1998-DATE 40-140HP 4-Stroke HC5358 HO6003 HO6002 See Note 2
2000-DATE 115HP FICHT HC5358 HO6003 HO6002 See Note 2
2002-DATE 200-225HP 4-Stroke HC5345 HO6003 HO6002
2005-DATE E250 DPX Vindicator HC5348 HO6003 HO6002
MERCURY 1984-1994 2.4/2.5HP EFI HC5345 HO6001 HO6002 See Note 4
1989-DATE 75-300HP HC5345 HO6001 HO6002 See Note 3
1996-DATE 75-200HP 2 & 4-Stroke HC5345 HO6001 HO6002
1998-DATE 30-60HP HC5345 HO6001 HO6002 See Note 2
2002-DATE 225HP 4-Stroke HC5358 HO6001 HO6002 See Note 1
2003-DATE 250-300HP XS HC5345 N/A HO6002 See Note 6
NISSAN 1990-DATE 90-140HP HC5345 HO6001 HO6002
SUZUKI 1986-DATE 100HP HC5345 HO6003 HO6002
1986-2002 115-140HP HC5345 HO6001 HO6002 NOT 1996
1986-DATE 150-300HP
2 & 4-Stroke
HC5345 HO6003 HO6002
1996 ONLY 115-140HP HC5348 HO6001 HO6002
1998-DATE 40-140HP 4-Stroke HC5358 HO6003 HO6002 See Note 2
2003-DATE 90HP 4-Stroke HC5358 HO6003 HO6002 See Note 2
US MARINE 1996-DATE 90-120HP HC5345 HO6001 HO6002
YAMAHA 1990-DATE 40-90HP HC5345 HO6003 HO6002
1986-DATE 100-250HP 2-Stroke HC5345 HO6001 HO6002
1997-DATE 80-225HP 4-Stroke HC5358 HO6001 HO6002 See Note 1
2000-DATE 150-250 HPDI HC5358 HO6001 HO6002 See Note 1
2002-DATE 300 HPDI HC5358 HO6001 HO6002
2003-DATE 25-60HP 4-Stroke HC5348 HO6003 HO6002 See Note 2
2006-DATE 350HP MUST Use Tournament Cylinders. Refer to Page 3-8
YANMAR 1994-DATE 90-120HP HC5345 HO6001 HO6002
3. Minimum Engine Center = 27"
4. May Require Extensive Cowling Modifications
5. HO5030 and HO5064 comes without Tie Bar
6. One cylinder per engine. Must use Mercury
supplied tiller bolt for installation.
1.
HC5345 is optional for SINGLE ENGINE
ONLY applications. DO NOT use HC5345
for twin engine applications as operational
interference may occur.
2. Requires Kit HO5090
Is your Splashwell wide enough? Check page 3-11 for space requirements.
NOTICE
The above engine applications are current through the revision date shown. For up-to-date engine applications go to: www.seastarsteerng.com
Prior to selecting a cylinder from this application guide, please refer
to page 3-4 to ensure that you are selecting the correct cylinder for
your engine/boat.
7. Interference will occur when using a single HC5345 cylinder
and HO6003 tiebar when installed in the aft hole on the
steering arm. Options include, a) install tiebar into most
forward hole (this will limit steering articulation), b) purchase
K-6 Cylinder, and tiebar kit part # HO5009. There will no be
no interference when using twin HC5345 cylinders.
