Edimax CV-7428nS User Manual

17
Note: Mac users can also use the Bonjour function of
Safari to access the browser based configuration
interface, as explained below.
Open Safari web browser and open the “Bookmarks” menu across the top of
the screen, and select “Show All Bookmarks”. Or you can click on the
bookmarks icon under the URL bar.
Then, select “Bonjour” from the menu in the left panel. Finally, click on
“edimax.go” in the lower panel on the right side.

Edimax CV-7428nS Specifications

Power

power adapter voltage	DC 5V
power adapter current	1A

Operating Environment

humidity	10-90% (Non-condensing)
temperature range	0-40°C
temperature range in Fahrenheit	32 - 104°F

Wireless Standards

frequency band	2.4 GHz
IEEE 802.11n data rate	up to 300Mbps
IEEE 802.11g data rate	up to 54Mbps
IEEE 802.11b data rate	up to 11Mbps

Ports & Interfaces

LAN ports	5 x RJ-45
antenna type	2 x 2dBi external antennas
LED indicators	Power, Wireless, LAN ports

Weight and Dimensions

weight	155 grams
height	30 mm
width	127 mm
depth	96 mm
