Edimax CV-7428nS User Manual

41
4. Click on “Ethernet” in the left panel and then click the drop down arrow for
the menu labeled “Configure IPv4” in the right panel. From the drop down
menu, select “Using DHCP” and then click “Apply”.
IV-1-2. How to modify the IP address of your PC or Macintosh
Please follow the instructions appropriate for your operating system. In the
following examples we use the IP address 192.168.9.20 though you can use
any IP address in the range 192.168.9.x (x = 3 – 254) in order to access the
browser based configuration interface.
Note: Please make a note of your static IP before
you change it. This is for your convenience if you
wish to modify the IP address of the wireless bridge
in future. To modify the IP address of the wireless
bridge, please refer to III-5. Administrator.
IV-1-2-1. Windows XP
1. Click the “Start” button (it should be located in the lower-left corner of your
computer), then click “Control Panel”. Double-click the “Network and
Internet Connections” icon, click “Network Connections”, and then
double-click “Local Area Connection”. The “Local Area Connection Status”
window will then appear, click “Properties”.

Edimax CV-7428nS Specifications

Power

power adapter voltage	DC 5V
power adapter current	1A

Operating Environment

humidity	10-90% (Non-condensing)
temperature range	0-40°C
temperature range in Fahrenheit	32 - 104°F

Wireless Standards

frequency band	2.4 GHz
IEEE 802.11n data rate	up to 300Mbps
IEEE 802.11g data rate	up to 54Mbps
IEEE 802.11b data rate	up to 11Mbps

Ports & Interfaces

LAN ports	5 x RJ-45
antenna type	2 x 2dBi external antennas
LED indicators	Power, Wireless, LAN ports

Weight and Dimensions

weight	155 grams
height	30 mm
width	127 mm
depth	96 mm
