Edimax CV-7428nS User Manual

34
follow the guide appropriate for your operating system in IV-1-2. How to
modify the IP address of your PC or Macintosh.
Note: For guidance on how to assign a new IP address
to the wireless bridge, so that it is within the same IP
address subnet of your network, please refer to III-5.
Administrator. In cases where you need to modify the
IP of your PC or Macintosh in order to access the
browser based configuration interface, if the default IP
of the wireless bridge remains unchanged, you may
need to repeat this process and modify the IP of your
PC or Macintosh every time you wish to configure the
wireless bridge.
IV-1-1. How to configure your computer to use a dynamic IP address
Please follow the instructions appropriate for your operating system.
IV-1-1-1. Windows XP
1. Click the “Start” button (it should be located in the lower-left corner of your
computer), then click “Control Panel”. Double-click the “Network and
Internet Connections” icon, click “Network Connections”, and then
double-click “Local Area Connection”. The “Local Area Connection Status”
window will then appear, click “Properties”.

Edimax CV-7428nS Specifications

Power

power adapter voltage	DC 5V
power adapter current	1A

Operating Environment

humidity	10-90% (Non-condensing)
temperature range	0-40°C
temperature range in Fahrenheit	32 - 104°F

Wireless Standards

frequency band	2.4 GHz
IEEE 802.11n data rate	up to 300Mbps
IEEE 802.11g data rate	up to 54Mbps
IEEE 802.11b data rate	up to 11Mbps

Ports & Interfaces

LAN ports	5 x RJ-45
antenna type	2 x 2dBi external antennas
LED indicators	Power, Wireless, LAN ports

Weight and Dimensions

weight	155 grams
height	30 mm
width	127 mm
depth	96 mm
