Edimax CV-7428nS User Manual

29
III-6. Configuration Tool
The wireless bridge’s configuration tool enables you to
back up or restore the settings, upgrade the firmware and
reset the device. Select “Configuration tool” from the
sidebar.
You will see the following screen:
Backup Settings
Click “Save” to save the current settings on
your computer as a config.bin file.
Restore Settings
Click the browse button to locate a
previously saved config.bin file and then
click “Upload” to upload the file and replace
your current settings.
Restore to
Factory Defaults
Click “Reset” to restore settings to the
factory default. A pop-up window will
appear and ask you to confirm and enter
your log in details. Enter your username and
password and click “Ok”. See below for
more information.
Note: Restoring settings to the factory default will
restore all settings, configurations and passwords

Edimax CV-7428nS Specifications

Power

power adapter voltage	DC 5V
power adapter current	1A

Operating Environment

humidity	10-90% (Non-condensing)
temperature range	0-40°C
temperature range in Fahrenheit	32 - 104°F

Wireless Standards

frequency band	2.4 GHz
IEEE 802.11n data rate	up to 300Mbps
IEEE 802.11g data rate	up to 54Mbps
IEEE 802.11b data rate	up to 11Mbps

Ports & Interfaces

LAN ports	5 x RJ-45
antenna type	2 x 2dBi external antennas
LED indicators	Power, Wireless, LAN ports

Weight and Dimensions

weight	155 grams
height	30 mm
width	127 mm
depth	96 mm
