Edimax CV-7428nS User Manual

62
extremely hot.
wireless bridge, the temperature of the device is at a
normal level.
b. If you smell burning or see smoke coming from wireless
bridge or A/C power adapter, then disconnect the wireless
bridge and A/C power adapter immediately, as far as it is
safely possible to do so. Call your dealer of purchase for
help.
My network
device can’t
access the
Internet.
a. Ensure that your broadband router is fully functional.
b. Switch off both your network device and wireless bridge,
and switch back on again.
c. Ensure that the wireless bridge is powered on (check the
PWR LED) and that the Ethernet cable is properly
connected to the network device.
d. Use a computer to access the CV-7428nS’s browser based
configuration interface. If something is wrong, you will see
an error page before the home page.
- On the home page, check “State” under “Wireless
Settings”. It should be “Connected” – if it is
“Disconnected” then this means the wireless bridge is not
connected to your router/access point.
My network is
using a static IP
address, how
do I assign an
IP address to
my wireless
bridge?
You can modify the IP address of the wireless bridge using
the browser based configuration interface. Please refer to
III-5. Administrator.
Netflix movies
are slow to
start playing.
Typically, enough of the movie is pre-loaded before playback
begins to ensure there are no interruptions during once
playback is under way. This is known as buffering. The speed
of your Internet connection is the most influential factor in
determining the length of time buffering – a slower
connection means more time buffering. For instant
streaming of standard definition content, generally an
Internet download speed of at least 2Mbps is necessary. For
instant HD streaming, download speeds of at least 5 Mbps
are generally required.
My Internet
connection is
fast enough,
It is possible the problem still lies with your Internet
connection.
a. Check and compare your connection speed at different

Edimax CV-7428nS Specifications

Power

power adapter voltage	DC 5V
power adapter current	1A

Operating Environment

humidity	10-90% (Non-condensing)
temperature range	0-40°C
temperature range in Fahrenheit	32 - 104°F

Wireless Standards

frequency band	2.4 GHz
IEEE 802.11n data rate	up to 300Mbps
IEEE 802.11g data rate	up to 54Mbps
IEEE 802.11b data rate	up to 11Mbps

Ports & Interfaces

LAN ports	5 x RJ-45
antenna type	2 x 2dBi external antennas
LED indicators	Power, Wireless, LAN ports

Weight and Dimensions

weight	155 grams
height	30 mm
width	127 mm
depth	96 mm
